| Place of Origin: | China |
| Brand Name: | JTP / YJL |
| Model Number: | 4JA1 |
| Certifiion: | ISO9001:2008;ISO/TS16949:2009 |
| Minimum Order Quantity: | 8pcs |
|---|---|
| Price: | negotiation |
| Packaging Details: | Packed in carton firstly,and then reinforced with green sack for outer packing |
| Delivery Time: | 5-10days |
| Payment Terms: | T/T or western Union |
| Supply Ability: | 2000pcs per month |
| OEM: | 8-97089-892-0 | LENGTH: | 87.8mm |
|---|---|---|---|
| CYL: | 6 | PIN SIZE: | 31x76mm |
| RING SIZE: | 2.0+2.0+4.0mm | CAR MAKE: | ISUZU |
| DIA: | 93.0mm | COMP: | 47.8mm |
| High Light: | icon forged pistons,cast iron piston |
||
4JA1 Appliion: PICK-UP SUV HILANDER/CROSSWIND No. CyI: 4 Diameter: 93.0MM |
|||||
| Piston | OEM No. | Compress Height | Total Length | Pin Size | Feature |
| 8-97089-892-0 | 47.8 | 87.8 | 31x76 | w/al-fin | |
| Piston Ring | OEM No. | Size1 | Size2 | ||
| 8-94247-867-0 | 2.0+2.0+4.0 | ||||
| Cylinder Liner | OEM No. | Size | Flange | ||
| 8-94110-144-0 | 93.0x95.0x156.0 | 101.0x0.9 | |||
| Engine Bearing | OEM No. | Main Bearing | Con Rod Bearing | Bush | |
| 8-94168-553 | 8-94324-159 | 8-94247-968 | |||
| Engine Valve (IN) | OEM No. | Head Diameter | Stem Diameter | Total Length | |
| 8-94122-275-1 | 40.1 | 8.0 | 118.1 | ||
| Engine Valve (EX) | OEM No. | Head Diameter | Stem Diameter | Total Length | |
| 8-94247-875-1 | 35.7 | 8.0 | 118.1 | ||
Our service:
1. Packaging is neutral packing or our packing
2. We will reply you within 24 hours.
3. We will also provide you with good after-sales service.
4. Small orders are welcomed.
5. Trial orders are acceptable
6. High quality and factory price.
7. 100% ensured the quality
Description:
A series of engine models for MITSUBISHI piston as below, there are many models not include in this sheet, pls also feel free enquiry from us.
| ISUZU | C240PK | 4 | 86 | 84.5 | 51.5 | |
| ISUZU | 4JA1 | 8-94152712-1 | 4 | 93 | 87.6 | 47.8 |
| ISUZU | 4JB1 | 8-94152711-0 | 4 | 93 | 92 | 51.8 |
| ISUZU | 4BD1 | 8-94422975-1 | 4 | 102 | 98 | 58.9 |
| ISUZU | 4BC2 | 5-12111-230-4 | 4 | 102 | 98 | 58.9 |
| ISUZU | 6BB1 | 5-12111-013-0 | 6 | 102 | 112.3 | 62.7 |
| ISUZU | 6BD1T | 5-12111-068-2 | 6 | 102 | 104.3 | 58.7 |
| ISUZU | 4BE1 | 8-94438989-1 | 4 | 105 | 95.7 | 56.4 |
| ISUZU | 6BG1 | 1-12111-323-2 | 6 | 105 | 95 | 55.5 |
| ISUZU | 6BF1 | 1-12111-345-0 | 6 | 105 | 110 | 58.75 |
| ISUZU | 10PA1 | 1-12111-154-1 | 10 | 115 | 113.2 | 75.2 |
| ISUZU | 10PB1 | 1-12111-217-0 | 10 | 115 | 104 | 67.8 |
| ISUZU | 10PC1 | 1-12111-419-1 | 10 | 119 | 104 | 67.7 |
| ISUZU | 10PD1 | 1-12111-549-3 | 10 | 119 | 106.5 | 67.5 |
| ISUZU | DH100 | 9-12111-742-3 | 6 | 120 | 150.83 | 77.8 |
| ISUZU | 6QA1 | 1-12111-388-1 | 6 | 125 | 136 | 83 |
| ISUZU | 6RB1 | 1-12111-437-0 | 6 | 135 | 142.9 | 82.1 |
| ISUZU | 6BG1(3R) | 6 | 105 | 94.5 | 35 | |
| ISUZU | 6BG1(4R) | 6 | 105 | 94.2 | 35 | |
| ISUZU | 4HG1 | 8-97183666-0 | 4 | 115 | 104.4 | 36 |
| ISUZU | 6SD1 | 1-12111-569-0 | 6 | 120 | 117 | 43 |
| ISUZU | 6SD1 | 6 | 120 | 117 | 43 | |
| ISUZU | DA120 | 6 | 100 | 125 | 34 | |
| ISUZU | DA640 | 6 | 102 | 125 | 36 | |
| ISUZU | 6HE1 | 6 | 110 | 119.8 | 40 | |
| ISUZU | 4HF1 | 8-97095-585-1 | 4 | 112 | 94.5 | 36 |
| ISUZU | 8-97176-655-0 | |||||
| ISUZU | 4HF1T | 5-87813-391-0 | 4 | 112 | 94.5 | 36 |
| ISUZU | 8-97176-656-0 |
4JA1 ENGINE PISTON PICTURE AS BELOW:
