74mm Diameter Cylinder Liner Sleeve 4K For Mitsubishi Engine Parts 11461-13010 Liner Kit

74mm Diameter Cylinder Liner Sleeve 4K For Mitsubishi Engine Parts 11461-13010 Liner Kit

  • 74mm Diameter Cylinder Liner Sleeve 4K For Mitsubishi Engine Parts 11461-13010 Liner Kit
  • 74mm Diameter Cylinder Liner Sleeve 4K For Mitsubishi Engine Parts 11461-13010 Liner Kit
  • 74mm Diameter Cylinder Liner Sleeve 4K For Mitsubishi Engine Parts 11461-13010 Liner Kit
  • 74mm Diameter Cylinder Liner Sleeve 4K For Mitsubishi Engine Parts 11461-13010 Liner Kit
74mm Diameter Cylinder Liner Sleeve 4K For Mitsubishi Engine Parts 11461-13010 Liner Kit
Product Details:
Place of Origin: China
Brand Name: JTP
Model Number: 4K
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: negotiation
Packaging Details: Packed in carton firstly,and then reinforced with green sack for outer packing
Delivery Time: Usually within one week after receive payment
Payment Terms: T/T or western Union
Supply Ability: 5000pcs per month
Contact Now
Detailed Product Description
Type: Dry Cylinder Liner Color: White
Diameter: 74mm Total Length: 140mm
Number Of Cylinder: 4 OEM: 11461-13010
Warranty: 100000 Miles Size: STD
Car Make: Mitsubishi Quality: High Quality
Material: Aluminum Steel
High Light:

cylinder liner sleeve

,

diesel engine cylinder liner

Cylinder liner/ Liner sleeve 4K For Mitsubishi engine parts 11461-13010 Liner kit





SPECIFIION:





E-Model OEM NO liner size Feature Weight/KG
    inside Bore Outside Bore Total Length
4K 11461-13010 75 79 140





Packaging Details All the products adopt independent packaging cartons with detailed goods packing list on carton
Delivery Detail 3-5 days if in stock piston or 45 days for production
Shipping Detail a.by express: Fedex, UPS, DHL,TNT
b. By sea: LCL or FCL cooperating with your appointed shipping agent or our own ones
74mm Diameter Cylinder Liner Sleeve 4K For Mitsubishi Engine Parts 11461-13010 Liner Kit 0







PRODUCT DETAILS


1) Cylinder linder/ sleeve is a cylindrial part, set within the cylinder block hole, and it forms combustor chamber with cylinder head & piston;

2) Cylinder liner/ sleeve is divided into two types: dry cylinder liner and wet cylinder liner;
Dry cylinder liner contact cooling water jacket on the back, but the back of the wet cylinder liner touch with cooling water;

3) Dry cylinder liner thickness thin, simple structure, convenient processing.
Wet cylinder liner contact cooling water directly, so for engine cooling, and for small, lightweight engine;

4) Material: alloy casting iron with phosphorus, boron & copper, steel;

5) Characteristics: good friction resistance, corrosion resistance, heat resistance, sufficient strength and rigidity, etc.;



Chemical Ingredients Of Cylinder Liner(%)
No. Name of Material C S Si P Mn Cr B Cu Ni V+Ti Mo Mechanical Properties
1 Boron Cast Iron 2.8~3.6 <=0.12 2.0~2.7 <=0.5 0.7~1.2 0.3~0.5 0.04~0.08         Brinell Hardness>210HB,
σb>=200Mpa
2 Boron Copper Gray Cast Iron 2.8~3.6 <0.2 2.0~2.7 <=0.5 0.7~1.2 0.2~0.5 0.04~0.08 Right
amount
      Brinell Hardness>210HB,
σb>=240Mpa
3 Vanadium, Titanium
Gray Cast Iron
3.0~3.6 <0.2 2.0~2.7 <=0.5 0.6~1.2 0.2~0.5       >=0.3   Brinell Hardness>210HB,
σb>200Mpa
4 Molybdenum Nickel
Copper Gray Cast Iron
2.8~3.6 <0.2 1.8~2.4 <=0.3 0.5~1.0 0.2~0.5   0.3~0.6 Right
amount
  Right
amount
Brinell Hardness>210HB,
σb>235Mpa
5 Bainite Gray Cast Iron 2.7~3.3 <0.10 1.7~2.5 <=0.3 0.3~0.7 0.~0.5   Right
amount
Right
amount
  Right
amount
Brinell Hardness270~330HB,
σb>350Mpa
6 Nickel Copper Gray Cast Iron 2.8~3.7 <0.12 1.8~2.7 <=0.3 0.5~1.2 0.15~0.5   Right
amount
Right
amount
    Brinell Hardness>200HB,
σb>196Mpa



74mm Diameter Cylinder Liner Sleeve 4K For Mitsubishi Engine Parts 11461-13010 Liner Kit 1
6) The function of cylinder liner/ sleeve
a) It froms cylinder working space together with the cylinder head & piston;

b) Gas seal: prevent the compressed gas, combustion gas pressure leak outward;

c) The trunk piston diesel engine cylinder liner piston under the lateral thrust, become a piston reciproing movement of the lead;

d) Heat transfer: passes the piston component and its heat to the cooling water, and makes the appropriate operating temperature;

e) The formation of sliding surface: as the lining of the engine, the format sliding surface with piston and piston ring;

f) Two-stroke diesel engine cylinder liner is decorated with port, opening & closing by the piston, so as to realize distribution;

7) Surface treatment: chromed, phospated, polished, aluminum inclusive;



Principal Surface Treatment Processes
DCP Phosphating and chromium plating on jacket only
DC Water jacket only is chromium plated
DPF Water jacket only is phosphated
BCP Phosphating and inner diameter is chromium
FF Inner diameter is Full-Finished for dry type liner
SF Inner diameter is Semi-Finished for dry type liner
IN WHITE Without any special surface treatment
DCU Outer diameter is cooper plated for dry type liner
PF Phosphated all over
  Air compression liner
  Chromed liner
  Liner


8) Machining process
Cylinder barrels: blanking---rough turning---heat treatment (conditioning)---turing(flat head chamfering)---coarse push inner hole---rolling inner hole---turing(external circular open nest)---turing inside hole---welding cylinder bottom---turing(cylindrical) according to the need to make internal zinc plated or chrome plated.





OUR EXHIBITION:



74mm Diameter Cylinder Liner Sleeve 4K For Mitsubishi Engine Parts 11461-13010 Liner Kit 2



ADVANTAGE:



1. High quality and competitive price.



2. Long life span, good sales-after service.



3. 100% new, strict inspection & test.



4. Standard export packing.



5. One year quality warranty.



6. Have strong stock, small order is acceptable



7. Various kinds are selectable with different car models.



8. Improve power and increase torque



9. Improve fuel economy and reduce fuel consumption



10. Reduce waste emissions and reduce environmental pollution





ADVANED PROCESSING TECHNOLOGY:

Our factory processing centers are adopted in the major process, with high processing precision and stable size; Inner circle honing use the texture standards for the advanced platform honing technology
74mm Diameter Cylinder Liner Sleeve 4K For Mitsubishi Engine Parts 11461-13010 Liner Kit 3




PRODUCTION FACILITIES:


1. IF melting furnace system


2. Insulation casting furnace system


3. Automatic casting line


4. Shot blasting machine


5. Fully automatic cutting line



Automatic casting and processing





DESTRIPTION:


A series of engine models for MITSUBISHI Cylinder liner as below, there are many models not include in this sheet, pls also feel free enquiry from us.



MITSUBISHI 4DQ5 30607-50301 4 83.0(SF) 84.0(FF) 162
MITSUBISHI 4D55/4D56 MD050430 MD103648-9 4 90.1(SF) 91.1(FF) 164.5
MITSUBISHI 4D55(N) 21131-42000 4 90.0(SF) 167
MITSUBISHI 4DR5/6DR5 31607-02202 31607-02101-2 4/6 91.0(SF) 92.0(FF) 176
MITSUBISHI S4S/S6S   4/6 93.0(SF) 190
MITSUBISHI 4M40T   4 94.0(SF) 160
MITSUBISHI 4M40   4 95.0(FF) 186
MITSUBISHI 4DR7   4 94.0(SF) 95.0(FF) 186
MITSUBISHI 4D30 ME011513 4 99.0(SF) 100.0(FF) 196.5
MITSUBISHI 4D31 ME011604-6 4 99.0(SF) 100.0(FF) 191.5
MITSUBISHI 4D31T 21131-41200 4 99.0(SF) 192
MITSUBISHI S4K/S6K 34307-00501 4/6 101.0(SF) 102.0(FF) 195
MITSUBISHI 4D32/4D34 ME012900 ME013366-7 4 103.0(SF) 104.0(FF) 197.5
MITSUBISHI 4D32T 21131-41300 4 103.0(SF) 192
MITSUBISHI 4D32(N) ME031502-4 4 103.0(SF) 104.0(FF) 192
MITSUBISHI 4D33 ME013333 4 107.0(SF) 108.0(FF) 197
MITSUBISHI 6D15-3AT ME071090 6 113.0(FF) 206 PF
MITSUBISHI 6D16 ME071224 6 118.0(FF) 204 PF
MITSUBISHI 6D16(new) ME041105-5 6 118.0(FF) 206 PF





FAQ:



1.Do you have other engine model?
Yes, we have a lot of engine model like 6D22, 8DC9, NT855, etc.

2.Are you trading company or manufacturer?
We are an engine parts trading company, a distributor of some manufacturers.

3.How long is your delivery time?
About 120 days. By DHL or TNT about 14 days after payment.

4.Do you provide samples? Is it free or extra?
Sorry we don't provide samples. Our minimum amount is ONE piece.

5.How to buy with you?
You can use "Chat now!" or email to us.

6.What kind of parts you supply?
We supply PISTON, PISTON RING, LINER, GASKET KIT, BEARING, etc.

7.If out of stock, how much time do you need to transfer from factory?
Piston ring is made in Japan need 5-6 month to transfer from Japan if out of stock.

8.What information should I let you know if I want to get a quotation?

To get an accurate quotation, please let us know the exact part name, quantity, quality level and trade terms like EXW, FOB and so on. More details provided will help.




CYLINDER LINER PICTURE AS BELOW:


74mm Diameter Cylinder Liner Sleeve 4K For Mitsubishi Engine Parts 11461-13010 Liner Kit 4
